HP Spectre x2

Infrared LED board
Description Spare part number
Infrared LED board (does not include infrared board cable)
NOTE: The infrared LED board spare part kit does not include the infrared LED board cable. The
infrared LED board cable is available using spare part number 924168-001.
924837-001
Before removing the infrared LED board, follow these steps:
1. Shut down the tablet. If you are unsure whether the tablet is o or in Hibernation, turn the tablet on,
and then shut it down through the operating system.
2. Disconnect all external devices connected to the tablet.
3. Disconnect the power from the tablet by rst unplugging the power cord from the AC outlet, and then
unplugging the AC adapter from the tablet.
4. Remove the display panel assembly (see Display panel assembly on page 20), and then remove
the following components:
a. Bottom bezel (see Bottom bezel on page 24)
b. Battery (see Battery on page 25)
c. Fan (see Fan on page 31)
d. Microphones (see Microphones on page 38)
e. Webcams (see Webcams on page 40)
f. Heat sink (see Heat sink on page 44)
g. System board (see System board on page 46)
h. Wireless antenna (see Wireless antenna on page 50)
Remove the infrared LED board:
▲
Remove the infrared LED board
Component replacement procedures 57
