• EMCLI Installed Path – (required) specifies the location of the installation path for the
Enterprise Manager Command Line Interface. You need to configure Enterprise Manager
Command Line Interface with Oracle Management Server (OMS) as a prerequisite step
(see “Prerequisites” (page 6)).
• The following plug-in instance properties are required for performance monitoring reports.
If you are not using performance monitoring reports, you can enter these values later.
◦ Array Serial No – specifies the serial number of the disk array that contains LUNs
for performance monitoring.
◦ LUNs for Performance Monitoring – specifies the LUNs to be monitored for
performance. The format is:
CU:LDEV.
Use a comma to list multiple LUNs:
15:08,15:09,15:0c,01:59,01:5a
◦ DB Instance for Performance Monitoring – specifies the database to be monitored
for performance. Enter the database instance names. Use a comma to list multiple
database names:
db1,db2,db3
NOTE: The Enterprise Manager Command Line Interface path field is mandatory
to successfully deploy the plug-in. However, the Array Serial No, LUNs for
Performance Monitoring, and DB Instance for Performance Monitoring properties
can be entered at a later time by clicking Monitoring Configuration in the plug-in
home page.
4. Click OK. A new target is added and appears in the agent’s monitored targets list.
Removing the plug-in
To remove the plug-in, you must undeploy it. To undeploy the plug-in:
1. Select HP StorageWorks P9000 Disk Array plug-in in management plug-in list and then click
the Undeploy icon.
2. Follow the steps provided by Enterprise Manager.
10 Installation and removal
