Table 3-2 Citrix ICA Connection Local Resources Options (continued)
Option Description
Drive Mapping
Enable Drive Mapping Allows you to specify drive mappings to local paths.
Table 3-3 Citrix ICA Connection Window Options
Option Description
Enable Seamless Window
Allows you to display a single window on the local ThinPro
desktop as if it were a native application.
Default Window Size
Establish the default window size. Options are: Full Screen,
Fixed Size, Percentage of Screen Size.
Default Window Colors
Establish the default window colors. Options are: 16, 256,
16-bit, 24-bit, Automatic.
Default 256 Color Mapping
This option is only enabled if Default Window Colors is set
to 256. Options are: Shared - Approximate Colors and
Private - Exact Colors.
Table 3-4 Citrix ICA Connection Firewall Options
Option Description
Proxy Proxy server settings.
Proxy Type
Options are: None - direct, SOCKS, Secure - HTTPS, Use browser settings,
Automatically detect proxy.
Proxy Address The IP address of the proxy server.
Proxy Port The port for connection to the proxy server.
Username The username to use for connection to the proxy server.
Password The password to use for connection to the proxy server.
Use Alternate Address for Firewall
Connection
The Citrix ICA Client will request the alternate address defined for the server when
contacting servers inside the firewall. The alternate address must be specified for
each server in a server farm.
Table 3-5 Citrix ICA Connection Server Location Options
Option Description
Default Protocol
The default protocol for this connection. Options are: TCP/IP Browser, TCP/IP
HTTP Browser, SSL/TLS HTTPS Browser.
TCP Address
The TCP address of the Citrix server. The three buttons enable you to add, edit or
delete entries from the list.
HTTP Address
The http address of the Citrix server. The three buttons enable you to add, edit or
delete entries from the list.
8 Chapter 3 Reference ENWW
