Table 3-45 Global Network Settings - Ethernet
Option Description
Link speed Sets the speed of the Ethernet link.
Duplex mode Sets the duplex mode of the Ethernet link.
●
Hosts - This tab can be used to display, add, or modify host name mappings.
3. Click Close to save your settings and close the dialog box.
Language
1. Double-click Language.
2. Select the language you want to use.
3. Click OK to save your changes and close the dialog box. A logout is required to make any
changes effective. A logout timer will start when you confirm these changes.
NOTE: The language can also be set by configuring Dynamic Host Configuration Protocol (DHCP)
tag 192 as a string whose value is English, German, Spanish, French, Japanese, or Simplified
Chinese.
Network Connections
To set Network attributes:
1. Double-click Network.
2. Configure the connections on the Wired, Wireless and VPN tabs.
3. To import a connection, click Import and browse to the connection.
4. To export a connection, select the connection and click Export.
5. Click Close to close the Network Connections dialog box.
You can configure wired, wireless, and VPN connections in this utility.
Wired Connection
Adding a Wired Network Connection
To add a wired network connection:
1. Click the Wired tab, and then click Add.
2. Choose whether or not to Connect automatically.
3. Configure the new setting by completing the information on the three tabs:
●
Wired
●
802.1x Security
●
IPv4 Settings
4. Click Apply to apply your settings and close the dialog box.
40 Chapter 3 Reference ENWW
