HP Vectra XE310 - System Board Connectors

If You Have a Problem
37 Troubleshooting Guide
System Board Connectors
Power connector
IDE device
(CD-ROM, DVD-ROM
or Zip drive)
IDE device
(Hard drive)
Floppy drive
CD audio connector
Status panel connector
Processor fan connector
Clear CMOS and
Clear Passwords
jumpers
IDE device
(CD-ROM, DVD-ROM
or Zip drive)
Power connector
Processor fan connector
HP Vectra XE310 Series 1 System Board
HP Vectra XE310 Series 2 System Board
IDE device
(Hard drive)
Floppy drive
CD audio connector
Clear CMOS and
Clear Passwords
jumpers
