To install the speakers, reverse this procedure.
Fan assembly
To remove the fan assembly, use this procedure and illustration.
Table 6-5
Fan description and part number
Description Spare part number
Fan assembly N13304-001
Before removing the fan assembly, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 37).
2. Remove the bottom cover (see Bottom cover on page 37).
3. Disconnect the battery cable from the system board (see Battery on page 39).
Remove the fan assembly:
1. Remove the power connector cable and WLAN antenna cables from the clips in the fan assembly (1).
2. Disconnect the fan cables from the system board (2).
3. Remove the six Phillips M2.0 × 3.5 screws (3) that secure the fan assembly to the computer.
46 Chapter 6Removal and replacement procedures for authorized service provider parts
