2. Remove the nine Phillips M2.0 × 4.0 screws that secure the system board to the computer.
3. Lift the right edge of the system board, and then pull the board up and to the right to remove it from the
computer (2).
To install the system board, reverse this procedure.
Touchpad
To remove the touchpad, use this procedure and illustration.
Table 6-11
Touchpad description and part number
Description Spare part number
Touchpad, ceramic white N13309-001
Touchpad, mica silver N13310-001
Touchpad, performance blue N13311-001
Touchpad cable N13312-001
Before removing the touchpad, follow these steps:
54
Chapter 6Removal and replacement procedures for authorized service provider parts
