3. Lift the back of the board up, and then pull the board into the computer to remove it (4).
To install theI/O board, reverse this procedure.
Card reader
To remove the card reader, use this procedure and illustration.
Table 6-8
Card reader description and part number
Description Spare part number
Card reader N13302-001
Card reader cable N13303-001
Before removing thecard reader, follow these steps:
1. Prepare the computer for disassembly (see Preparation for disassembly on page 37).
2. Remove the bottom cover (see Bottom cover on page 37).
3. Remove the battery (see Battery on page 39).
Remove the card reader board:
1. Disconnect the cable from the ZIF connector on the system board (1).
2. Remove the Phillips M2.0 × 4.0 screw (2) that secures the bracket, and then remove the bracket (3).
3. Remove the two Phillips M2.0 × 2.5 screws (4) that secure the card reader to the computer.
Card reader
49
