Right side
Component Description
(1) microSD memory card reader Reads optional memory cards that enable you to store,
manage, share or access information.
To insert a card:
1. Hold the card label-side up, with connectors facing the
computer.
2. Insert the card into the memory card reader, and then
press in on the card until it is rmly seated.
To remove a card:
▲ Press in on the card, and then remove it from the
memory card reader.
(2) micro-HDMI port Connects an optional video or audio device, such as a high-
denition television, any compatible digital or audio
component, or a high-speed High-Denition Multimedia
Interface (HDMI) device.
(3) AC adapter and battery light
●
White: The AC adapter is connected and the battery is
fully charged.
●
Blinking white: The AC adapter is disconnected and the
battery has reached a low battery level.
●
Amber: The AC adapter is connected and the battery is
charging.
●
O: The battery is not charging.
(4) USB Type-C power connector port Connects a USB device with a Type-C connector to an AC
adapter to provide power to the computer and allows data
transfer.
NOTE: Adapters (purchased separately) may be required.
(5) USB 3.0 port Connects an optional USB device such as a keyboard, mouse,
external drive, printer, scanner or USB hub.
6 Chapter 2 External component identication
