Item Component Spare part number
(1) Display panel assembly
Silver HP x2 and HP x2 210 G2 models 902380-001
White HP x2 models 902381-001
Red HP x2 models 902382-001
Display panel cable (not illustrated) 902354-001
(2) Battery, 2-cell, 32-Wh (includes cable) 859517-855
(3) Audio board bracket 902361-001
(4) Audio board 902368-001
Audio board cable (not illustrated) 902351-001
(5) RTC battery 902383-001
(6) Power button board 902369-001
Power button board cable (not illustrated) 902352-001
(7) Speaker Kit (includes left and right speakers and cables) 902391-001
(8) Rear webcam (includes bracket) 902256-001
(9) Front webcam (includes microphone rubber) 902255-001
Front webcam cable (not illustrated) 902355-001
(10) Antenna 902341-001
(11) Volume board 902370-001
Volume board cable (not illustrated) 902353-001
(12) Docking connector 902356-001
(13) LCD shielding (includes thermal pad) 902363-001
(14) System board equipped with an Intel Atom x5-z8350 processor and a graphics subsystem with UMA memory (includes
replacement thermal material)
For use in HP x2 210 G2 models:
●
Equipped with a 128-GB eMMC hard drive (SoC), 4 GB of system memory, and the
Windows 10 operating system
903879-601
●
Equipped with a 128-GB eMMC hard drive (SoC), 4 GB of system memory, and Windows
7 or a non-Windows operating system
903879-001
For use in HP x2 and HP x2 210 G2 models:
●
Equipped with a 64-GB eMMC hard drive (SoC), 4 GB of system memory, and the
Windows 10 operating system
902254-601
●
Equipped with a 64-GB eMMC hard drive (SoC), 4 GB of system memory, and Windows
7 or a non-Windows operating system
902254-001
●
Equipped with a 32-GB eMMC hard drive (SoC), 2 GB of system memory, and the
Windows 10 operating system
902251-601
●
Equipped with a 32-GB eMMC hard drive (SoC), 2 GB of system memory, and Windows
7 or a non-Windows operating system
902251-001
10 Chapter 3 Illustrated parts catalog
