HP Z1 Maintenance And Service Guide

A Linux technical notes
HP offers a variety of Linux solutions for HP workstation customers:
●
HP certifies and supports Red Hat Enterprise Linux (RHEL) on HP workstations.
●
HP certifies SUSE Linux Enterprise Desktop (SLED) on HP workstations.
●
HP offers a SLED 11 preload on some Z Series workstations.
For Linux setup and restore procedures, see the user guide for your workstation at
http://www.hp.com/support/workstation_manuals.
Topics
System RAM on page 97
Audio on page 97
Network cards on page 98
Hyper-Threading Technology on page 98
NVIDIA Graphics Workstations on page 99
NOTE: After you set up the operating system, make sure that the latest BIOS, drivers, and software
updates are installed.
CAUTION: Do not add optional hardware or third-party devices to the workstation until the
operating system is successfully installed. Adding hardware might cause errors and prevent the
operating system from installing correctly.
System RAM
HP supports different amounts of total RAM in various HP workstations, based on the number of
hardware DIMM slots and the capabilities of the system. The total memory supported for each
configuration is listed in the Hardware Support Matrix for HP Linux Workstations at
http://www.hp.com/support/linux_hardware_matrix.
Audio
All HP workstations come with built-in audio hardware. The audio hardware is supported by the
Advanced Linux Sound Architecture (ALSA) drivers included with all modern Linux distributions.
The audio hardware provides basic playback and recording features. The ability to simultaneously play
audio from multiple sources, such as applications and CDs, is provided by software mixing functionality
in the ALSA driver. The performance of software audio mixing and playback functionality is greatly
improved in ALSA version 1.0.13 and later drivers.
System RAM
97

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
