HP Z1 Maintenance And Service Guide

Asset tracking
Asset tracking features provide asset tracking data that can be managed using HP Systems Insight
Manager (HP SIM), HP Console Management Controller (CMC), or other systems-management
applications.
Seamless, automatic integration between asset tracking features and these products enables you to
choose the management tool that is best suited to the environment and to leverage investments in
existing tools.
HP also offers several solutions for controlling access to valuable components and information:
●
HP ProtectTools Embedded Security prevents unauthorized access to data, checks system integrity,
and authenticates third-party users attempting system access.
●
Security features such as ProtectTools and the Smart Cover Sensor (side access panel sensor) help
prevent unauthorized access to the data and to the internal components of the computer.
●
By disabling parallel, serial, or USB ports, or by disabling removable-media boot capability, you
can protect valuable data assets.
●
Memory Change and Side access panel sensor (Smart Cover Sensor) alerts can be forwarded to
system management applications to deliver proactive notification of tampering with a computer’s
internal components.
ProtectTools, the Smart Cover Sensor, and the side access panel solenoid lock (Hood Lock) are
available as options on select systems.
You can manage security settings as follows:
●
Locally, with Computer Setup (F10) Utility
●
Remotely, with HP CMS or HP System Software Manager (SSM), which enable the secure,
consistent deployment and control of security settings from a simple command line utility
For more information about Computer Setup (F10) Utility, see
Computer Setup (F10) Utility menu
on page 15.
The following Computer Setup (F10) Utility features let you manage computer security.
Table 2-2 F10 security features overview
Feature Purpose
Removable Media Boot Control Prevents booting from removable media drives
Serial, Parallel, USB, or Infrared
Interface Control
Prevents transfer of data through the integrated serial, parallel, USB, or infrared
interface
Power-On Password
Prevents use of the computer until the password is entered (applies to initial system
startup and restarts)
Setup Password
Prevents reconfiguration of the computer (through the Setup utility) until the
password is entered
Network Server Mode Provides unique security features for computers used as servers
Desktop management
29

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
