Side components
Figure 1-2 Side components
Table 1-2 Component descriptions
1 Power button 6 IEEE-1394a FireWire® connector
2
Hard drive activity light 7 USB 3.0 connectors (2)
3
Slot-load optical drive eject button
and activity LED
8
Headphone connector
4 Slot-load optical drive 9
Microphone connector
5 xD/MMC/MS/SD card reader
Side components
3
