After the NVIDIA proprietary driver is installed, the optional NVIDIA graphics devices supported in the
HP Z1 Workstation also provide audio functionality over HDMI, which can be passed through the
external DisplayPort connector to a monitor with audio capabilities. Such a configuration may present
two audio hardware choices. If you do not hear sound through the speakers, one possible reason is
that the NVIDIA audio device has been chosen by default. Check the audio settings (for example,
Sound in GNOME Control Center).
Network cards
All HP workstations include one or two integrated network interface controllers. The HP Z1 Workstation
includes a PCI Express Mini Card that implements both wireless LAN and Bluetooth. The iwlagn driver
supports the wireless LAN; in most distributions, the Network Manager automatically senses that
wireless networks are available. Bluetooth support is also available in many Linux distributions.
Hyper-Threading Technology
The Z Series workstations support Hyper-Threading Technology (HTT), an Intel-proprietary technology
that improves processor performance through parallelization of computations (doing multiple tasks at
once). The operating system treats an HTT-enabled processor as two virtual processors and shares the
workload between them when possible. This feature requires that the operating system support multiple
processors and be specifically optimized for HTT.
To enable HTT:
1. During startup, press F10 to enter Computer Setup (F10) Utility. Use the arrow keys to navigate
and select options.
2. Select Advanced > Device Options.
3. Set Hyper-Threading to Enable, and then press F10 to exit the menu.
4. Select File > Save Changes and Exit.
5. Restart the system to enable HTT.
NOTE: On most recent Linux distributions (including RHEL 5, RHEL 6, SLED 11, and updates to those
streams), the kernel automatically detects that HTT is enabled and works correctly.
98 Appendix A Linux technical notes

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
