HP Z1 Maintenance And Service Guide

Personal
grounding
methods and
equipment
Use the following items to help prevent ESD damage:
●
Wrist straps — These are flexible straps with a maximum of one megohm ± 10% resistance
in the ground cords. To provide a proper ground, wear the strap against bare skin. The
ground cord must be connected and fit snugly into the banana plug connector on the
grounding mat or computer.
●
Heel straps, toe straps, and boot straps — These can be used at standing computers
and are compatible with most types of shoes or boots. On conductive floors or dissipative
floor mats, use them on both feet with a maximum of one megohm ± 10% resistance between
the operator and ground.
Static shielding
materials
Static shielding materials provide the following levels of protection.
Method
Antistatic plastic
Carbon-loaded plastic
Metalized laminate
Voltage
1,500V
7,500V
15,000V
Grounding the
work area to
prevent static
damage
●
Cover the work surface with approved
static-dissipative material. Use a wrist
strap connected to the work surface, and
properly grounded tools and equipment.
●
Use static-dissipative mats, foot straps, or
air ionizers to give added protection.
●
Handle electrostatic-sensitive
components, parts, and assemblies by
the case or PCB laminate. Handle them
only in static-free work areas.
●
Disconnect power and input signals before
inserting and removing connectors or test
equipment.
●
Use fixtures made of static-safe materials
when fixtures must directly contact
dissipative surfaces.
●
Keep work area free of nonconductive
materials, such as plastic assembly aids and
Styrofoam.
●
Use field service tools (such as cutters,
screwdrivers, and vacuums) that are
conductive.
Recommended
ESD prevention
materials and
equipment
●
Antistatic tape
●
Antistatic smocks, aprons, and sleeve
protectors
●
Conductive bins and other assembly or
soldering aids
●
Conductive foam
●
Conductive tabletop computers with a
ground cord of one megohm ± 10%
resistance
●
Static-dissipative table or floor mats with
a hard-tie to ground
●
Field service kits
●
Static awareness labels
●
Wrist straps and footwear straps providing
one megohm ± 10% resistance
●
Material-handling packages
●
Conductive plastic bags
●
Conductive plastic tubes
●
Conductive tote boxes
●
Opaque shielding bags
●
Transparent metallized shielding bags
●
Transparent shielding tubes
Product recycling
HP encourages customers to recycle used electronic hardware, HP original print cartridges, and
rechargeable batteries.
Product recycling
43

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
