HP Z1

Rear components
Figure 1-3 Rear components (excluding stand)
Table 1-3 Component descriptions
1 Handle 6 Power cord connector
2
Subwoofer connector (orange) 7 USB 2.0 connectors (4)
3
Audio line-out connector (green) 8 Optical S/PDIF audio output
4
Audio line-in connector (blue) 9 RJ-45 network connector
5
DisplayPort connector (output/input) 10 Cable lock slot
4 Chapter 1 Hardware overview
