HP Z1 Maintenance And Service Guide

Table 4-4 External display problems (continued)
Problem Cause Solution
Fuzzy focus; streaking,
ghosting, or shadowing
effects; horizontal
scrolling lines; faint
vertical bars; unable to
center the picture on
the screen (flat-panel
monitors using an
analog VGA input
connection only.)
Flat-panel monitor’s internal
digital conversion circuits might
be unable to correctly interpret
the output synchronization of the
graphics card.
1. Select the monitor’s Auto-Adjustment option in the
monitor’s onscreen display menu.
2. Manually synchronize the Clock and Clock Phase
onscreen display functions.
Some typed symbols do
not appear correctly.
The font you are using does not
support that symbol.
Use the Character Map to locate and select the appropriate
symbol.
Select Start > All Programs > Accessories >
System Tools > Character Map. You can copy the
symbol from the Character Map into a document.
The graphics driver does is not
working properly or does not
support the symbol set with that
resolution.
Try either solution:
●
Change the panel resolution in the Windows Control
Panel > Screen Resolution menu or through the
control panel for the graphics controller (Intel or
nVidia).
●
Install the latest graphics driver:
1. Boot into the OS and uninstall the graphics driver.
2. Restart the computer.
3. Install the latest graphics driver for your graphics
controller.
Troubleshooting scenarios and solutions
71

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
