HP Z1 Maintenance And Service Guide

Table 4-7 Diagnostic lights and audible codes (continued)
Activity Possible cause Recommended action
Red Power LED blinks
three times, once every
second, followed by a
two-second pause. Three
beeps.
CPU not installed (not an
indicator of bad CPU).
CAUTION: Internal components might be powered even when
the computer is off. To prevent damage, disconnect the computer
power cord before you remove a component.
1. Verify that the CPU is present.
2. Reseat the CPU.
Red Power LED blinks four
times, once every second,
followed by a two-second
pause. Four beeps.
Power failure (power
supply is overloaded).
CAUTION: Internal components might be powered even when
the computer is off. To prevent damage, disconnect the computer
power cord before you remove a component.
1. Open the access panel and ensure that all power
connections are secure on the system board.
2. Check if a device is causing the problem by removing all
attached devices (such as hard disks optical disk drives, and
expansion cards.) Power on the computer. If the system
enters the POST, power off and replace one device at a
time; repeat this procedure until failure occurs. Replace the
device that is causing the failure. Continue adding devices
one at a time to ensure all devices are functioning properly.
Red Power LED blinks five
times, once every second,
followed by a two-second
pause. Five beeps.
Pre-video memory error. CAUTION: Internal components might be powered even when
the computer is off. To prevent damage, disconnect the computer
power cord before you remove a component.
1. Reseat DIMMs.
2. Replace DIMMs one at a time to isolate faulty module.
3. Replace third-party memory with HP memory.
4. The problem might be on the system board. Contact HP for
assistance.
Red Power LED blinks six
times, once every second,
followed by a two-second
pause. Six beeps.
Pre-video graphics error. CAUTION: Internal components might be powered even when
the computer is off. To prevent damage, disconnect the computer
power cord before you remove a component.
Try these solutions in this order:
●
Reseat the graphics card if using nVidia graphics; reseat the
processor if using Intel HD Graphics.
●
Replace the graphics card if using nVidia graphics or
replace the processor if using Intel HD graphics.
●
Replace the system board.
Processor does not
support graphics output
and no discrete graphics
card is installed.
Either install a processor with Intel HD Graphics, or install a
supported graphics card.
Red Power LED blinks
seven times, once every
second, followed by a
two- second pause. Seven
beeps.
System board failure
(ROM detected failure
prior to video).
1. Clear CMOS.
NOTE: See
Clearing and resetting the CMOS
on page 95 for details.
2. The problem might be on the system board. Contact HP for
assistance.
84 Chapter 4 Diagnostics and troubleshooting

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
