HP Z1 Maintenance And Service Guide

Table 4-9 POST error messages (continued)
Screen message Probable cause Recommended action
510—Splash Screen image
corrupted
Splash Screen image has errors. Update system UEFI.
511—CPU Fan not detected Fan is not connected or is defective. 1. Reseat the fan cable.
2. Reseat the fan.
3. Replace the fan.
515—CPU Overtemp occurred Insufficient processor cooling or
processor defect.
1. If necessary, add a heatsink to the
processor and ensure proper operation.
2. Replace the processor.
516—MXM fan not detected MXM fan missing, disconnected, or
defective.
1. Reseat the fan cable.
2. Reseat the fan.
3. Replace the fan.
517—Memory fan not
detected
Memory fan missing, disconnected,
or defective.
1. Reseat the fan cable.
2. Reseat the fan.
3. Replace the fan.
530—Left DMIC cable not
connected.
Left Dmic cable is not connected to
the system board or to the left Dmic.
1. Reseat the cable.
2. Replace the cable.
531—Right DMIC cable not
connected.
Right Dmic cable is not connected to
the system board or to the right
Dmic.
1. Reseat the cable.
2. Replace the cable.
532—Side I/O board not
connected.
Side I/O board is missing or is not
connected.
1. Reseat the Side I/O board.
2. Replace the Side I/O board.
3. Replace the system board.
533—Rear I/O USB/Audio
cable not connected.
The Rear I/O USB/Audio cable
between the system board and Rear
I/O board is missing or not
connected.
1. Reseat the cable.
2. Replace the cable.
534—Rear I/O DP/LAN cable
not connected.
The Rear I/O DP/LAN cable
between the system board and Rear
I/O board is missing or not
connected.
1. Reseat the cable.
2. Replace the cable.
535—LED Backlight cable not
connected.
The LED Sync/backlight cable
between the system board and the
LCD panel is missing or not
connected.
1. Reseat the cable.
2. Replace the cable.
536—LCD DP cable not
connected.
The LCD DP cable between the
system board and the LCD panel is
missing or not connected.
1. Reseat the cable.
2. Replace the cable.
90 Chapter 4 Diagnostics and troubleshooting

HP Z1 Specifications

General

Tcase	72.6 °C
Bus type	DMI
Stepping	D2
FSB Parity	No
Processor cache	8 MB
Processor cores	4
Processor model	E3-1245
System bus rate	5 GT/s
Processor series	Intel Xeon E3-1200
Processor socket	LGA 1155 (Socket H2)
Processor threads	8
Processor codename	Sandy Bridge
Processor frequency	3.3 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor front side bus	- MHz
PCI Express slots version	2.0
Processor boost frequency	3.7 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	95 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	33
Maximum number of PCI Express lanes	20
Memory types supported by processor	DDR3-SDRAM
Memory clock speeds supported by processor	1066, 1333 MHz
Memory bandwidth supported by processor (max)	21 GB/s
Maximum internal memory supported by processor	32 GB
Audio system	HD
Product type	Workstation
Motherboard chipset	Intel® C206
Memory slots	4x DIMM
Internal memory	4 GB
Memory channels	Dual-channel
Memory clock speed	1600 MHz
Memory layout (slots x size)	- GB
Resolution	2560 x 1440 pixels
Graphics card	Quadro 500M
Networking features	Gigabit Ethernet (10/100/1000)
Wireless technology	802.11 a/g/n
Graphics card family	NVIDIA
Maximum storage capacity	2 TB
HDD speed	7200 RPM
RAID levels	0, 1
HDD capacity	1000 GB
HDD interface	SATA
Optical drive type	DVD Super Multi
Maximum graphics card memory	1.024 GB
On-board graphics card model	Intel® HD Graphics P3000
On-board graphics card family	Intel® HD Graphics
On-board graphics card base frequency	850 MHz
On-board graphics card dynamic frequency (max)	1350 MHz
Number of displays supported (on-board graphics)	2
Display diagonal	27 \
Display number of colors	1.073 billion colors
Modem (RJ-11) ports	0
USB 2.0 ports quantity	7
Bundled software	Roxio Easy Media Creator; Intervideo WinDVD
Operating system installed	Windows 7 Professional
Power supply	400 W
Power supply input voltage	100 - 240 V
Power supply input frequency	50 - 60 Hz
Certification	Energy Star
Product color	Black
Country of origin	China
Processor code	SR00L
Processor ARK ID	52274
Processor package size	37.5 x 37.5 mm
Supported instruction sets	AVX
Intel Identity Protection Technology version	1.00

Weight and Dimensions

Depth	419.1 mm
Width	660.4 mm
Height	584.2 mm
Weight	213.2 g
