HP Z220 SFF Series User Manual

HP Z220 SFF Workstation components
This section describes the HP Z220 Small Form Factor (SFF) Workstation components.
For complete and current information on supported accessories and components for the computer, see
http://partsurfer.hp.com.
Z220 SFF Workstation front panel
Figure 2-1 Front panel components
Table 2-1 Component description
1 Optical drive 5
Optional media card reader (shown)
or optional second hard disk drive
2
Power button 6
Hard drive or optical drive activity
light
3
USB 2.0 ports (4, black) 7 Headphones connector
4
Microphone or headphones connector
(software selectable, default mode is
microphone)
8 Chapter 2 Workstation features

HP Z220 SFF Series Specifications

General

Chipset	Intel C216
Form Factor	Small Form Factor (SFF)
Processor Options	Intel Core i3, i5, i7
Memory	Up to 32GB DDR3 (4 DIMM slots)
Storage Options	SATA HDD or SSD
Graphics	Integrated Intel HD Graphics; Optional NVIDIA or AMD discrete graphics
Operating System	Windows 7, Windows 8, Linux (optional)
Power Supply	240W 90% efficient
Dimensions	100 x 338 x 381 mm (3.95 x 13.3 x 15 in)
Weight	Starting at 7.6 kg (16.75 lbs)
Audio	Integrated HD Audio
Expansion Slots	1 PCIe x16, 1 PCIe x1, 1 PCI
Ports	USB 2.0, USB 3.0, DisplayPort, VGA, audio in/out
Optical Drive	DVD-ROM, DVD+/-RW SuperMulti
