HP Z220 SFF Series User Manual

HP Z620 Workstation components
HP Z620 Workstation front panel
Figure 2-7 Front panel components
Table 2-7 Component descriptions
1 Optical drive 5 USB 3.0 ports (2, blue)
2
Power button 6 Headphone connector
3
Hard drive activity light 7 Microphone connector
4
USB 2.0 port (black) 8 IEEE–1394a FireWire connector
14 Chapter 2 Workstation features

HP Z220 SFF Series Specifications

General

Chipset	Intel C216
Form Factor	Small Form Factor (SFF)
Processor Options	Intel Core i3, i5, i7
Memory	Up to 32GB DDR3 (4 DIMM slots)
Storage Options	SATA HDD or SSD
Graphics	Integrated Intel HD Graphics; Optional NVIDIA or AMD discrete graphics
Operating System	Windows 7, Windows 8, Linux (optional)
Power Supply	240W 90% efficient
Dimensions	100 x 338 x 381 mm (3.95 x 13.3 x 15 in)
Weight	Starting at 7.6 kg (16.75 lbs)
Audio	Integrated HD Audio
Expansion Slots	1 PCIe x16, 1 PCIe x1, 1 PCI
Ports	USB 2.0, USB 3.0, DisplayPort, VGA, audio in/out
Optical Drive	DVD-ROM, DVD+/-RW SuperMulti
