HP Z220 SFF Series User Manual

Connecting and configuring monitors
NOTE: The graphic cards that HP supports typically allow at least two monitors, as shown in this
section; some supported cards allow more monitors. Refer to the graphics card documentation for
details.
1. Connect the monitor cable adapters (1) (if required) to the workstation, then connect the
appropriate monitor cables to the adapters (2) or directly to the graphics card.
Figure 3-4 Connecting the cables to the workstation
2. Connect the other ends of the graphics cables to the monitors.
Figure 3-5 Connecting cables to the monitors
3. Connect one end of the monitor power cord to the monitor and the other end to a grounded
power outlet.
4. Configure the monitor. For details, refer to Microsoft Help or to
http://www.microsoft.com, or to
your Linux Help or website.
Adding monitors
27

HP Z220 SFF Series Specifications

General

Chipset	Intel C216
Form Factor	Small Form Factor (SFF)
Processor Options	Intel Core i3, i5, i7
Memory	Up to 32GB DDR3 (4 DIMM slots)
Storage Options	SATA HDD or SSD
Graphics	Integrated Intel HD Graphics; Optional NVIDIA or AMD discrete graphics
Operating System	Windows 7, Windows 8, Linux (optional)
Power Supply	240W 90% efficient
Dimensions	100 x 338 x 381 mm (3.95 x 13.3 x 15 in)
Weight	Starting at 7.6 kg (16.75 lbs)
Audio	Integrated HD Audio
Expansion Slots	1 PCIe x16, 1 PCIe x1, 1 PCI
Ports	USB 2.0, USB 3.0, DisplayPort, VGA, audio in/out
Optical Drive	DVD-ROM, DVD+/-RW SuperMulti
