HP Z220 SFF Series User Manual

Using HP Windows 8 restore media (purchased separately)
To order HP Windows 8 restore media, go to http://www.hp.com/support, select your country or
region, and follow the on-screen instructions. You can also order the media by calling support.
CAUTION: Using HP Windows 8 restore media completely erases hard drive contents and reformats
the hard drive. All files that you have created and any software that you have installed on the computer
are permanently removed. When reformatting is complete, the recovery process helps you restore the
operating system, as well as drivers, software, and utilities.
To initiate recovery using HP Windows 8 restore media:
NOTE: This process takes several minutes.
1. If possible, back up all personal files.
2. Insert the Windows 8 OS DVD.
3. Restart the computer, and then follow the instructions provided with the Windows 8 operating
system media to install the operating system.
4. When prompted, press any keyboard key.
5. Follow the on-screen instructions.
After the operating system install is completed:
1. Remove the Windows 8 operating system media, and then insert the Driver Recovery media.
2. Install the Hardware Enabling Drivers first, and then install Recommended Applications.
Backup and recovery in Windows 8
43

HP Z220 SFF Series Specifications

General

Chipset	Intel C216
Form Factor	Small Form Factor (SFF)
Processor Options	Intel Core i3, i5, i7
Memory	Up to 32GB DDR3 (4 DIMM slots)
Storage Options	SATA HDD or SSD
Graphics	Integrated Intel HD Graphics; Optional NVIDIA or AMD discrete graphics
Operating System	Windows 7, Windows 8, Linux (optional)
Power Supply	240W 90% efficient
Dimensions	100 x 338 x 381 mm (3.95 x 13.3 x 15 in)
Weight	Starting at 7.6 kg (16.75 lbs)
Audio	Integrated HD Audio
Expansion Slots	1 PCIe x16, 1 PCIe x1, 1 PCI
Ports	USB 2.0, USB 3.0, DisplayPort, VGA, audio in/out
Optical Drive	DVD-ROM, DVD+/-RW SuperMulti
