Using recovery media
CAUTION: System Recovery deletes all data and programs you have created or installed. Back up
any important data to a CD or DVD or to a USB flash drive.
To create recovery media, see
System recovery using recovery media on page 36.
To perform a System Recovery using recovery media:
1. If using a set of DVDs, insert the first recovery disc into the DVD drive tray, and close the tray. If
you are using a recovery USB flash drive, insert it into a USB port.
2. If the computer is not responding, press and hold the power button for approximately 5 seconds or
until the computer turns off.
or
Click the Start button, and then click Shut Down.
3. Disconnect all peripheral devices from the computer except the monitor, keyboard, and mouse.
4. Press the power button to turn on the computer.
5. Press Esc as the computer is powering on to see the startup menu. Use the arrow keys to select the
boot menu and press Enter. Use the arrow keys to select the location where the recovery media is
inserted (USB or DVD). Press Enter to boot from that device.
6. If Recovery Manager asks if you want to run System Recovery from Media or Hard Drive, select
Media. On the Welcome screen, under I need help immediately, click Factory Reset.
7. If you are prompted to back up your files, and you have not done so, select Back up your files
first (recommended), and then click Next. Otherwise, select Recover without backing
up your files, and then click Next.
8. If you are prompted to insert the next recovery disc, do so.
9. When Recovery Manager is finished, remove the recovery disc or the recovery USB flash drive
from the system.
10. Click Finish to restart the computer.
38 Chapter 4 Setting up and restoring Windows 7

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the HP Z220 SFF Series and is the answer not in the manual?

HP Z220 SFF Series Specifications

General IconGeneral
ChipsetIntel C216
Form FactorSmall Form Factor (SFF)
Processor OptionsIntel Core i3, i5, i7
MemoryUp to 32GB DDR3 (4 DIMM slots)
Storage OptionsSATA HDD or SSD
GraphicsIntegrated Intel HD Graphics; Optional NVIDIA or AMD discrete graphics
Operating SystemWindows 7, Windows 8, Linux (optional)
Power Supply240W 90% efficient
Dimensions100 x 338 x 381 mm (3.95 x 13.3 x 15 in)
WeightStarting at 7.6 kg (16.75 lbs)
AudioIntegrated HD Audio
Expansion Slots1 PCIe x16, 1 PCIe x1, 1 PCI
PortsUSB 2.0, USB 3.0, DisplayPort, VGA, audio in/out
Optical DriveDVD-ROM, DVD+/-RW SuperMulti
