HP Z24m G3 User Manual

10
9
#ASSY Main Chassis Z24m
1
10
#Screw
4
11
#Side USB Holder Z24m
1
12
#ASSY Side USB BD Z24m
1
13
#ASSY Rear Cover Z24m
1
14
#ASSY Hinge Z24m/Z24U
1
15
#Screw
4
16
#Hinge Cover Z24m
1
17
#ASSY Stand ARM Lift Z24m
1
18
#ASSY Stand Base Z24m
1
19
#Joystick Cap Z Series
1
20
#ASSY OSD BD Z Series
1
21
#Screw
4
22
#Screw
4
23
#ASSY Bezel Bottom Z24m
1
24
#ASSY Power Key BD Z24m
1
25
#Screw
5
26
#Power Mylar Z24m
1
27
#ASSY Power BD Z24m
1
28
#Screw
1
29
#ASSY Speaker Z24m
1
30
#ASSY Webcam Switch BD Z24m
1
How to order parts
The HP authorized repair center can purchase the power board from HP.
Power board
Description
HP spare part number
Manufacturer part number
PWR BD MG238HC-BQCW(C)Z24m G3 BOE
P D
N12332-001
755.08102.0001
Capacitors and connectors are available for purchase from the following EU distributors:
 TC (RUBYCON ALU CAP): www.thin-chan.com.tw
 CAPXON: www.capxongroup.com
Capacitors by distributor
Component
description
Location
Component
distributor
Distributor part number
CAP EL 470U 35V M P5
10*16 ZH
AC714,AC715,AC717,AC718
CAPXON
ZH471M035G160ETABHR

HP Z24m G3 Specifications

General

Color depth	8 bit
Color gamut	99 %
Pixel pitch	0.21 x 0.21 mm
Screen shape	Flat
Pixel density	123 ppi
Display diagonal	23.8 \
Anti-glare screen	Yes
Native aspect ratio	16:9
Maximum refresh rate	90 Hz
Contrast ratio (typical)	1000:1
Display number of colors	1.07 billion colors
Display diagonal (metric)	60.45 cm
Digital horizontal frequency	30 - 140 kHz
Display brightness (typical)	400 cd/m²
Supported graphics resolutions	640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA), 1024 x 768 (XGA), 1280 x 1024 (SXGA), 1280 x 720 (HD 720), 1440 x 900, 1600 x 900, 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA)
HDMI version	1.4
USB upstream port type	USB Type-C
USB Type-A downstream ports quantity	4
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	170 W
Power consumption (standby)	0.5 W
Power consumption (typical)	38 W
Operating temperature (T-T)	5 - 35 °C
Operating relative humidity (H-H)	20 - 80 %
Package type	Box
Package depth	48.4 mm
Package height	311.7 mm
Package weight	8200 g
Pivot angle	-90 - 90 °
Tilt angle range	-5 - 20 °
Height adjustment	150 mm
Panel mounting interface	100 x 100 mm
Product color	Silver
Market positioning	Business
Megapixel	5 MP
RMS rated power	10 W
Number of speakers	2

Weight and Dimensions

Depth (with stand)	195 mm
Width (with stand)	538.3 mm
Height (with stand)	489.3 mm
Weight (with stand)	5700 g
Depth (without stand)	141 mm
Width (without stand)	625 mm
Height (without stand)	387 mm
