HPE G2 R6000 User Manual

Power protection specifications
UPS model VA Nominal power rating
(W)
Output voltage setting
G2 R5000 5000 4500 200/208/220/230/240
G2 R6000 5000 4500 200/208/220/230/240
G2 R6000 IEC 5200 4600 200/208/220/230/240
Voltage specifications
Configuration setting (VAC) Available nominal output voltage (VAC)
G2 R5000 4out NA/JPN 208V
G2 R5000 5out NA/JPN 208V
G2 R6000 INTL 230V
Output tolerance specifications
Source of power Regulation
Utility power Sync with line ±5% of nominal line frequency
Battery power ±0.5% of auto-selected nominal frequency
Output feature specifications
Feature Specification
Online efficiency 92.8% nominal input voltage
Voltage wave shape Sinewave
Surge-suppression IEC62040-2 C3 4kV L-PE, 2kV L-L
Noise filtering IEC62040-2 C3
Battery specifications
Feature Specification
Type 12VDC, sealed, maintenance-free, rechargable, valve-regulated, lead-
acid batteries with a 3-year service life at 25ºC (77ºF)
Voltage The battery modules have a battery string voltage of 180 V.
Average battery runtime
Average battery runtimes are approximate and vary depending on connected equipment, configuration,
battery age, temperature, and so on. These estimates are based on the batteries at beginning of life.
36 Specifications

HPE G2 R6000 Specifications

General

Form Factor	Rack-mountable
Battery Type	Sealed Lead-Acid (SLA)
Nominal Output Voltage	230 V
Frequency	50/60 Hz
Input Voltage	200 V AC to 240 V AC
Output Voltage	200 V AC to 240 V AC
Interface	USB
Capacity	6000 VA
Battery Runtime	Varies based on load (typically 5-15 minutes at full load)
