Item Description
5 M.2 connectors
6 Internal USB 30 ports
7 x1 SATA port 4
8 Optical disc drive/SATA port 5
9 Power switch/SID module connector
10 Drive backplane power connectors
11 Energy pack connector
12 Chassis intrusion detection switch connector
13 Drive backplane power connector
14 microSD card slot
15 NVMe connector (port 7b)
16 NVMe connector (port 8b)
17 Smart Array modular controller connector
18 Secondary PCIe riser connector
1
19 System battery
20 Tertiary PCIe riser connector
1
21 TPM connector
22 Serial port connector
1
The secondary and tertiary risers require a second processor.
System maintenance switch descriptions
Position
Default Function
S1
1
O • O = iLO security is enabled.
• On = iLO security is disabled.
S2 O Reserved
S3 O Reserved
S4 O Reserved
S5 O • O = Power-on password is enabled.
• On = Power-on password is disabled.
S6
2
,
3
O • O = No function
• On = Restore default manufacturing settings
S7 O Reserved
Table Continued
Component identification 21
