Table 17: SN6000B 16Gb FC Switch power supply specifications
Specification Values
Input voltage Range: 85–264 VAC Auto-volt, Nominal: 100–240 VAC, 2.0 A, 47–
63 Hz; the switch autosenses input voltage
Input frequency Range: 47–63 Hz; Nominal: 50–60 Hz
Inrush current Maximum of 50 A peak at 240 VAC for any initial current surge or
spike of 10 ms or less at cold startup. Additional inrush current
surges or spikes in the form of AC cycles, or multiple AC cycles
greater than 10 ms and less than 150 ms, must not exceed 15 A
peak.
Single power supply output 150 W at 12 VDC
Maximum current 12.5 A at 12 VDC
Input line protection Both AC lines are fused
System power consumption 110 W with all 48 ports populated with 16 Gb/s SWL optical media
72 W with empty chassis and no optical media
Table 18: SN3000B 16Gb FC Switch power supply specifications
Specification Values
Input voltage Range: 85–264 VAC, nominal: 100–240 VAC
Input frequency Range: 47–63 Hz; Nominal: 50–60 Hz
Inrush current Maximum of 35 A peak at 240 VAC for 10 ms or less
Single power supply output 150 W at 12 VDC
Input line protection AC lines are fused
System power consumption 80 W with all 24 ports populated with 16 Gb/s SWL optical media
60 W with empty chassis and no optical media
Specifications 79
