Table 19: StoreFabric SN4000B SAN Extension Switch power supply
specifications
Specification Values
Input voltage Range: 90–264 VAC, Nominal: 100–240 VAC, 50–60 Hz. 200–240
VAC is recommended.
The switch autosenses input voltage.
Input frequency Nominal: 50–60 Hz
Inrush current Maximum of 40 A peak at any initial current surge at cold or warm
start
Maximum input current 12-5 A
Input line protection AC lines are fused
Maximum output power rating
(DC)
1
1100 W
1
The SN4000B SAN Extension Switch does not support DC power supply.
Environmental requirements
HPE SN6000B and SN3000B 16Gb FC switches environmental requirements lists the acceptable
environmental ranges for both operating and nonoperating (such as during transportation or storage)
conditions.
Table 20: HPE StoreFabric SN6500B 16Gb FC Switch environmental requirements
Condition Acceptable range during operation Acceptable range during nonoperation
Ambient
temperature
0º to 40ºC (32º to 104ºF) -25º to 70ºC (-13º to 158ºF)
Humidity 10% to 85% RH noncondensing, at 40ºC
(104ºF)
10% to 90% RH noncondensing, at 70ºC
(158ºF)
Altitude 0 to 3 km (9,842 ft) above sea level 0 to 12 km (39,370 ft) above sea level
Shock 20 G, 6 ms, half-sine wave 33 G, 11 ms, half-sine wave, 3/e.g. Axis
Vibration 0.5 G sine, 0.4 gms random, 5–500 Hz 2.0 G sine, 1.1 gms random, 5–500 Hz
Airflow Maximum: 176.7 cubic m/h (104 cubic
ft/m)
Nominal: 52.7 cubic m/h (31 cubic f/m)
N/A
Heat
dissipation
1,378.5 BTU/hr (no optics configuration)
1,706.1 BTU/hr (fully populated port
configuration)
N/A
80 Environmental requirements
