HPRT FC53-Li User Manual

FC53-Li/FC53-Lc/FC53-Ri/FC53-Rc User Manual
Rev.2.0
17
1.7 Specifications
(1/3)
Items
Specifications
Model Name
FC53-Li (Left, Intermittent),FC53-Lc (Left, Continuous), FC53-Ri (Right, Intermittent),
FC53-Rc (Right, Continuous)
Structure
All-metal structure
Print Mode
Thermal transfer printing
Print Width (Max.)
53 mm (300dpi)
Print Area
53mm*75mm (Intermittent), 53mm*100mm (Continuous)
Resolution
300 dpi (12 dots/mm)
Print Speed
40 - 600mm/s
Processor
32-bit RSIC processor
Flash Memory
8MB (minimum)
Dynamic Memory
16MB (minimum)
Real-time Clock
Function
STD, battery discharge life is at least 3 years
Detector
Ribbon tension detection; thermal head position detection; cover open detection;
TPH over temperature detection; ribbon break detection
Flexible Packaging
Inspection
Electromagnetic induction or synchronizer
Flexible Packaging
Materials
PVDC, PET, PE, NY, CPP, OPP, BOPP, BOPET, BOPA, CPP, PE, VMPET, VMCPP and
other films and composite films
Ribbon Capacity
1 ”mandrel with a maximum length of 1100 meters
Ribbon Type
Type: Wax / Resin
Resin width: 20 mm (0.79 ") to 55 mm (2.17")
Ribbon Saving
Support for multiple ribbon savings modes
；
The minimum ribbon interval between two lines of printing is not more than 0.5mm
Air Supply
Max. 6 bar/90 psi
Air Consumption
As low as 4 ml / print at 2.5 bar
Print Density Level
Level 31
