MINIKEY User Manual Add content to your layout
Page 34 of 66 HSA SYSTEMS
Stamps
Although having their own button for quick access, STAMPS content actually is a
logo.
When you create a stamp by stamp menu=>NEW you are presented with selection of
the stamp and properties.
If you press SHIFT+STAMP you are instead presented with a visual list of the stamps
currently installed.
Select by cursor up/down or left/right and ENTER to select – or just type a 2 digit
number if you know it already.
Then you are presented with options for the stamp chosen.
Property Description
Name Descriptive name, must be unique to the layout, and can not be empty.
X Position in the horisontal direction, starting from upper left corner. The distance is set
in current units (mm/inch/pixel)
Y Position in the vertical direction, starting from upper left corner. The distance is set in
current units (mm/inch/pixel)
Size Either half (150 pixel high / ½ pen) or 300 pixel high / 1 pen.
Size is scaled correctly according to content.
Stamp A visual representation of the stamp selected. Press enter here to select another
stamp
A collection of stamps may be up to 50 different stamps. It is possible to create these
via MiniDraw. You can also upload your own images if you prefer instead. As long as
the size is adequate from the beginning (300 pixel in height per print engine)
See instruction in MiniDraw how to do this.
