How to test your equipment
When the MINIKEY is being installed, you can check that all hardware connected to
the controller is working as expected.
Select Test I/O in the settings menu. Shortcut “5”
On this screen you will find the start switch, the encoder plus the input and output
channels.
When a signal is ON, the light bulb will light up.
Example:
Activate your start switch. If the controller receives a signal from the start switch, the
light bulb will light up. Start your conveyor. If the controller receives a signal the
lightbulbs "encoder a" and "encoder b" will start flashing.
Press “1” or “2” to toggle the output signals
