HT PQA400 User Manual

PQA400 - PQA823 - PQA824
EN - 19
12/09/2006 – 16:55:10
TOTAL POWER VALUES – Page x/y
Patt
Preatt
Papp
Pf
CosPhi
=
=
=
=
=
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
Pact  Total Active Power
Preact  Total Reactive Power
Papp  Total Apparent Power
Pf  Total Power Factor
CosPhi  Total Power factor considering fundamental
 of voltage and current signals
Fig. 20: Page of total power values
12/09/2006 – 16:55:10
PHASE 1 RMS VALUES – Page x/y
V1N
I1
Patt1
Preatt1
Papp1
Pf1
CosPhi1
=
=
=
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V1N  Phase-Neutral voltage L1 phase
I1  Current on L1 phase
Pact1  Active Power L1 phase
Preact1  Reactive Power L1 phase
Papp1  Apparent Power L1 phase
Pf1  Power factor L1 phase
CosPhi1  Power factor between fundamental of
 voltage L1 and current L1
Fig. 21: Page of Phase 1 values
12/09/2006 – 16:55:10
PHASE 2 RMS VALUES – Page x/y
V2N
I2
Patt2
Preatt2
Papp2
Pf2
CosPhi2
=
=
=
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V2N  Phase-Neutral voltage L2 phase
I2  Current on L2 phase
Pact2  Active Power L2 phase
Preact2  Reactive Power L2 phase
Papp2  Apparent Power L2 phase
Pf2  Power factor L2 phase
CosPhi2  Power factor between fundamental of
 voltage L2 and current L2
Fig. 22: Page of Phase 2 values
12/09/2006 – 16:55:10
PHASE 3 RMS VALUES – Page x/y
V3N
I3
Patt3
Preatt3
Papp3
Pf3
CosPhi3
=
=
=
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V3N  Phase-Neutral voltage L3 phase
I3  Current on L3 phase
Pact3  Active Power L3 phase
Preact3  Reactive Power L3 phase
Papp3  Apparent Power L3 phase
Pf3  Power factor L3 phase
CosPhi3  Power factor between fundamental of
 voltage L3 and current L3
Fig. 23: Page of Phase 3 values
