PQA400 - PQA823 - PQA824
EN - 48
5.4.6. General Parameters
This option permits the selection of network parameters for recording operation. This level
included several sub-level for a detailed selection depending on the type of system on test
(see § 5.3.1).
Depending on the selection performed, different error screen can be shown by meter. The
below situations are possible:
12/09/2006 – 16:55:10
RECORDING SETTINGS
+
General Parameters
+
Harmonics
Voltage Anom.: 230V 6% -10%
Inrush current: 30A 1s fix
Flicker
Unbalance
Error: no selected parameters
CLP/EXP PREDEF. SEL MODIFY
Fig. 92: General Parameters section: no selection
Fig. 92 shows the situation which the error due to no parameters selection is performed
also if the “General Parameters” is selected at display. Please note the text on grey
background and the not selected check box. In this situation other type of analysis as
Harmonics, Voltage Anomalies, Flicker, etc.. are not possible. Pressing F3 key (or touch
“SEL” at display) to exit from this error condition. In this order the flag of “General
Parameters” check box it will be selected and the below screen (with black text
background) is shown:
12/09/2006 – 16:55:10
RECORDING SETTINGS
+
General Parameters
+
Harmonics
Voltage Anom.: 230V 6%-10%
Inrush current: 30A 1s fix
Flicker
Unbalance
96/251 Parameters – Autonomy: 9d 4h
CLP/EXP PREDEF. SEL MODIFY
Fig. 93: General Parameters section: selected parameters
In example of the above picture 96 parameters are been selected on total of maximum 251
available and the correspondent autonomy is shown automatically by meter in this case.
CAUTION
The “General Parameters” check box activated flag, automatically select the
main electrical parameters whose number depends on the selected system
(Voltages, Currents, Frequency, Power Factor, Active, Reactive, Apparent
Powers, Active, Reactive, Apparent Energies). The failure to select “General
Parameters” flag automatically doe not select the above parameters.
