5.2.4. Single phase system – Screens sequence
12/09/2006 – 16:55:10
PHASE 1 RMS VALUES – Page x/y
V1N
VNPE
Freq
I1
Patt1
Preatt1
Papp1
Pf1
CosPhi1
=
=
=
=
=
=
=
=
=
0.0 V
0.0 V
0.0 Hz
0.0 A
0.0 W
0.0 VAr
0.0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V1N  Phase-Neutral voltage L1 phase
VNPE  Neutral-Ground voltage
Freq  Frequency
I1 
Current on L1 phase
Pact1  Active Power L1 phase
Preact1  Reactive Power L1 phase
Papp1  Apparent Power L1 phase
Pf1  Power factor L1 phase
CosPhi1  Power factor between fundamental of
 voltage L1 and current L1
Fig. 42: Page of numerical values
12/09/2006 – 16:55:10
FLICKER – Page 2/2
V1N
Pst1’ 0.0
Pst
0.0
Pst max
0.0
Plt
0.0
Plt max
0.0
Recording Time: 00h – 00min
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
Pst1’  Short term severity after 1minute
Pst  Short term severity
Pstmax  Maximum short term severity
Plt  Long term severity
Pltmax  Maximum long term severity
Recording Time  Real time duration of recording
expressed in HH:MM
Fig. 43: Page of Flicker values
25/01/2013 – 16:55:10
TOT. ENERGY CONSUMPTION – Page x/y
Eact = 0 kWh
Ppeak = 0 kW
Date Ppeak : -- / -- / -- 00:00:00
Start rec. : -- / -- / -- 00:00:00
Stop rec. : -- / -- / -- 00:00:00
Rec. Time : - - -
Int. Per. : - - - Rec: - -
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
Eact Total active energy consumed when starting
recording.
Ppeak  Maximum peak of consumed active power.
Date Ppeak  Date and time in which the peak occurred.
Start rec.  Date when recording was started.
Stop rec.  Date when recording was stopped.
Rec. Time  Time elapsed from Rec Start.
Int. Per.  Value of the set integration period.
Rec  Number of the recording in progress
Fig. 44: Consumed energy page
CAUTION
The Total Consumed Energy page is shown only if the instrument has been
set for the Recording of the General Parameter Total “Active Power &
Energy” (see § 5.4.6.1). Values will be shown only during or at the end of a
recording and zeroed upon starting a new recording or when the instrument
is switched off
