PQA400 - PQA823 - PQA824
EN - 24
5.2.3. 3-wire ARON three phase system – Screens sequence
12/09/2006 – 16:55:10
TOTAL RMS VALUES – Page x/y
V12
0.0
V23
0.0
V31
0.0
V
NEG%
0.0
ZERO%
0.0
SEQ
000
Hz
0.0
I1
0.0
I2
0.0
I3
0.0
A
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V12 Phase L1 – Phase L2 voltage
V23 Phase L2 – Phase L3 voltage
V23 Phase L3 – Phase L1 voltage
NEG% Unbalance percentage of negative tern
ZERO% Unbalance percentage of zero tern
SEQ phases sequence indication as:
”123” = > Corrected
”132” = > Reversed
”023” = > Null voltage on the Black wire
”103” = > Null voltage on the Red wire
”120” = > Null voltage on the Brown wire
”100” = > Null voltage on the Red and Brown wires
”020” = > Null voltage on the Black and Brown wires
”003” = > Null voltage on the Black and Red wires
Hz Frequency
I1 Current on L1 phase
I2 Current on L2 phase
I3 Current on L3 phase
Fig. 36: Page of numerical values
12/09/2006 – 16:55:10
WATTMETER12 – Page x/y
V12
I1
Patt12
Preatt12
Papp12
Pf12
CosPhi12
=
=
=
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V12 Phase L1 – Phase L2 voltage
I1 Current on L1 phase
Pact12 Active Power Wattmeter 12
Preact12 Reactive Power VARmeter 12
Papp12 Apparent Power VAmeter 12
Pf12 Power Factor Wattmeter 12
CosPhi12 Power Factor between fundamental of
voltage and current Wattmeter 12
Fig. 37: Page of numerical values Wattmeter-Varmeter 1-2
12/09/2006 – 16:55:10
WATTMETER32 – Page x/y
V32
I3
Patt32
Preatt32
Papp32
Pf32
CosPhi32
=
=
=
=
=
=
=
0.0
V
0.0
A
0 W
0
Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V32 Phase L3 – Phase L2 voltage
I3 Current on L3 phase
Pact32 Active Power Wattmeter 32
Preact32 Reactive Power VARmeter 32
Papp32 Apparent Power VAmeter 32
Pf32 Power Factor Wattmeter 32
CosPhi32 Power Factor between fundamental of
voltage and current Wattmeter 32
Fig. 38: Page of numerical values Wattmeter-Varmeter 3-2
