HT PQA400 User Manual

PQA400 - PQA823 - PQA824
EN - 22
12/09/2006 – 16:55:10
PHASE 1 RMS VALUES – Page x/y
V1PE
I1
Patt1
Preatt1
Papp1
Pf1
CosPhi1
=
=
=
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V1PE  Phase L1-PE voltage
I1  Current on L1 phase
Pact1  Active Power L1 phase
Preact1  Reactive Power L1 phase
Papp1  Apparent Power L1 phase
Pf1  Power factor L1 phase
CosPhi1  Power factor between fundamental of
 voltage L1 and current L1
Fig. 30: Page of numerical values of Phase 1
12/09/2006 – 16:55:10
PHASE 2 RMS VALUES – Page x/y
V2PE
I2
Patt2
Preatt2
Papp2
Pf2
CosPhi2
=
=
=
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V2PE  Phase L2-PE voltage
I2  Current on L2 phase
Pact2  Active Power L2 phase
Preact2  Reactive Power L2 phase
Papp2  Apparent Power L2 phase
Pf2  Power factor L2 phase
CosPhi2  Power factor between fundamental of
 voltage L2 and current L2
Fig. 31: Page numerical values of Phase 2
12/09/2006 – 16:55:10
PHASE 3 RMS VALUES – Page x/y
V3PE
I3
Patt3
Preatt3
Papp3
Pf3
CosPhi3
=
=
=
=
=
=
=
0.0 V
0.0 A
0 W
0 Var
0 VA
0.00i
0.00i
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
V3PE  Phase L3-PE voltage
I3  Current on L3 phase
Pact3  Active Power L3 phase
Preact3  Reactive Power L3 phase
Papp3  Apparent Power L3 phase
Pf3  Power factor L3 phase
CosPhi3  Power factor between fundamental of
 voltage L3 and current L3
Fig. 32: Page numerical values of Phase 3
12/09/2006 – 16:55:10
FLICKER – Page x/y
V1PE V2PE V3PE
Pst1’ 0.0
0.0 0.0
Pst
0.0 0.0 0.0
Pst max
0.0 0.0 0.0
Plt
0.0 0.0 0.0
Plt max
0.0 0.0 0.0
Recording Time: 00h – 00min
PAGE SCOPE HARM VECTORS
PARAMETERS CAPTION:
Pst1’  Short term severity after 1 minute
Pst  Short term severity
Pstmax  Maximum short term severity
Plt  Long term severity
Pltmax  Maximum long term severity
Recording Time  real time duration of recording
expressed in HH:MM
Fig. 33: Page of Flicker values
