PQA400 - PQA823 - PQA824
EN - 64
INRUSH
GENERAL MENU PARAMETER SETTINGS SYSTEM
Analyzer Settings
System
Not modified Each system
Freq[Hz]
Clamp Type
FS Clamp[A]
VT Ratio
Analyzer Settings
Advanced
Zoom Graphics
Harm. Type
Harm. Values
Zoom 1st Harm.
Average Values
Recording Settings
Comments INRUSH
Each system
Start Not modified
Stop Not modified
Integration period 1s
Cogeneration OFF
General Parameters
V1N, VN-PE, I1, Hz Single phase
V1-PE, V2-PE,
V3-PE, V12, V23, V31
I1, I2, I3, Hz
3-wire
V12, V23, V31
I1, I2, I3, Hz
ARON
V1N, V2N, V3N, VN-PE
I1, I2, I3, IN (only PQA82x), Hz
4-wire
P1, Q1i, Q1c, S1, Pf1, Cosphi1,
Ea1, Eri1, Erc1
Single phase
Pt, P1, P2, P3, Qti, Qti1, Qti2, Qti3,
Qtc, Qtc1, Qtc2, Qtc3, St, S1, S2, S3,
Pft, Pf1, Pf2, Pf3, Cosphit, Cosphi1,
Cosphi2, Cosphi3, Eat,Eat1, Eat2,
Eat3, Erit, Eri1, Eri2, Eri3, Erct, Erc1,
Erc2, Erc3
3-wire, 4-wire
Pt, P12, P32, Qti, Q12i, Q32i, Qtc,
Q12c, Q32c, St, S12, S32, Pft, Pf12,
Pf32, Cospht, Cosphi12, Cosphi32,
Eat, Ea12, Ea32, Erit, Eri12, Eri32,
Erct, Erc12, Erc32
ARON
Voltage harmonics THD, DC, h1, h2, h3…h15
Each system
Current harmonics THD, DC, h1, h2, h3…h15
Voltage anomalies ON
Ref. Voltage anomalies
230V Single, 4-wire
400V 3-wire, ARON
Up threshold anomalies +6%
Each system
Low threshold anomalies -10%
Inrush current (only
PQA82x)
ON (10A, 1s, var)
Flicker OFF
Unbalance
Not available Single phase
ON 3/4-wire, ARON
Spike (only PQA824) OFF Each system
Table 10: Selected parameters of START-UP configuration
