HTC Shift User Manual

Appendix 117
UMTS/HSDPA/GSM/EDGE Data Function
Network Quad-band GSM/GPRS/EDGE 850, 900, 1800, 1900
Tri-band HSDPA/UMTS: Europe/US: 850/1900/2100
Japan: 800/2100
HSDPA: Up to 3.6Mbps for download, 384kbps for upload
UMTS: Up to 384kbps for download and upload
(The device will operate depending on the frequency
bands supported by the wireless service provider)
Internal Antenna Yes
Global Roaming Yes
Auto Band
Switching
Yes
Physical
Dimensions 207 mm (L) x 129 mm (W) x 25 mm (T)
Weight 800 g (with battery)
Camera Module
Type Color CMOS VGA camera for videoconferencing
Connections
I/O Port 1 USB 2.0 host
D-Sub VGA out
3.5mm stereo audio out with microphone
Wireless
Connections
Bluetooth® 2.0, Wi-Fi® (IEEE 802.11 b/g)
Audio
Input Built-in microphone
Speaker Dual speakers

HTC Shift Specifications

General

Display diagonal	7 \
Display resolution	800 x 480 pixels
HDD capacity	40 GB
ROM capacity	128 MB
Internal memory	1 GB
Internal memory type	-
Compatible memory cards	SDIO
Built-in processor	A110
Processor frequency	0.8 GHz
RFID reader	No
Product color	Gray
Phone function	Yes
Keyboard layout	QWERTY
Bluetooth version	2.0+EDR
Networking features	IEEE 802.11 b/g
Operating frequency	850/1900/2100, 850/900/1800/1900 MHz
Rear camera resolution	640 x 480 pixels
Speakers	stereo
I/O ports	1x VGA out
Interface	USB 2.0
Headphone outputs	1
Standby time	240 h
Battery capacity	2700 mAh
Battery life (max)	- h
AC adapter input voltage	90 - 265 V
AC adapter output current	3 A
AC adapter output voltage	12 V
Manageability features	Left/right mouse buttons, microPad

Weight and Dimensions

Depth	129 mm
Width	207 mm
Height	25 mm
Weight	800 g
