Getting Started 17
Left side
Headset/MIC
Connect stereo headphones,
speakers, or a microphone.
Stylus
Press the stylus to eject it from the stylus
compartment, and slide it out.
Right side
USB 2.0 Port
Connect a USB device such as
a printer, mouse, etc.
POWER/HOLD Switch
Slide to the right and release to:
• Power on the Mobile Computer.
• Put Windows to sleep mode; wake Windows from sleep mode.
Sliding the switch to the left puts it in hold. (You will see an
orange dot.) This prevents accidental keyboard or touch screen
actions when the Mobile Computer is in the carrying case.
SDIO Card Slot
Use it as an SD
memory card reader.
DC-In
Connect the
AC adapter
to this jack
Back side
VGA Port
Connect an external monitor when you need to
use dual display.
