Board Optional/
Mandatory
Maximum
Number
Slot Restriction
UTRP Optional 2 Slot 0, 1, 4, 5, or
6
A single UTRP
is preferentially
configured in
slot 4. If more
UTRPs are
required, the
UTRP is
installed, in
descending
order of priority,
in slot 4, 5, 0, 1,
or 6.
If several
UTRPs are
configured, the
priority of them
as following:
UTRPc,
UTRP6,
UTRP9,
UTRP2,
UTRP3/UTRP4
USCU
Optional 1 Slot 1 or 0 It is
preferentially
configured in
slot 1.
When
configured with
two satellite
cards, it is
configured in
slot 1 (with both
slots 0 and 1
occupied).
Figure 3-6 shows the typical configurations of the BBU3900 UMTS.
Figure 3-6 Typical configuration of the BBU3900 UMTS
BTS3900C (Ver.C)
Hardware Description 3 BTS3900C Modules
Issue 03 (2013-05-27) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
19
