Board Signaling Specification (CAPS)
LBBPd1/LBBPd2/LBBPd3 60
The following table lists the maximum RRC_connected users supported by the LBBP.
Table 3-46 Maximum RRC_connected users
Board Cell Bandwidth Maximum RRC_Connected
Users
LBBPc 1.4 MHz 1008
3 MHz 1800
5 MHz 1800
10 MHz 1800
15 MHz 1800 (2R)/1200 (4R)
20 MHz 1800 (2R)/1200 (4R)
LBBPd1/LBBPd2 1.4 MHz 504
3 MHz 1080
5 MHz 1800
10 MHz 3600
15 MHz 3600
20 MHz 3600
LBBPd3 1.4 MHz 1008
3 MHz 2160
5 MHz 3600
10 MHz 3600
15 MHz 3600
20 MHz 3600
The maximum number of data radio bearers (DRBs) supported by the LBBP is three times the
maximum RRC_connected users.
NOTE
For the signaling specifications of an entire eNodeB, see section "Signaling Specifications" in 3900 Series
Base Station Technical Description. For the following specifications, see section "Baseband
Specifications" in 3900 Series Base Station Technical Description: the maximum number of data radio
bearers, maximum RRC_connected users per cell, maximum RRC_connected users supported by an entire
base station, and maximum uplink and downlink throughput per cell or user.
BTS3900C (Ver.C)
Hardware Description 3 BTS3900C Modules
Issue 03 (2013-05-27) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
62
