Huawei BTS3900C User Manual

The following table lists the maximum throughput of the LBBP.
Table 3-47 Maximum throughput of the LBBP
Board Maximum Throughout
LBBPc
l Downlink: 300 Mbit/s
l Uplink: 100 Mbit/s
LBBPd1
l Downlink: 450 Mbit/s
l Uplink: 225 Mbit/s
LBBPd2
l Downlink: 600 Mbit/s
l Uplink: 225 Mbit/s
LBBPd3
l Downlink: 600 Mbit/s
l Uplink: 300 Mbit/s
The following table lists the number of cells, bandwidth, and antenna configurations supported
by a single LBBP in LTE FDD scenarios.
Table 3-48 Specifications of the LBBP in LTE FDD scenarios
Board
Number of
Cell
Cell Bandwidth Antenna Configuration
LBBPc 3 1.4 MHz, 3 MHz, 5 MHz, 10
MHz, 15 MHz, and 20 MHz
3x20 MHz 1T1R
3x20 MHz 1T2R
3x10 MHz 4T4R
3x20 MHz 2T2R
1x20 MHz 4T4R
LBBPd1
3 1.4 MHz, 3 MHz, 5 MHz, 10
MHz, 15 MHz, and 20 MHz
3x20 MHz 1T1R
3x20 MHz 1T2R
3x20 MHz 2T2R
LBBPd2 3 1.4 MHz, 3 MHz, 5 MHz, 10
MHz, 15 MHz, and 20 MHz
3x20 MHz 1T1R
3x20 MHz 1T2R
3x20 MHz 2T2R
3x20 MHz 4T4R
LBBPd3 6 1.4 MHz, 3 MHz, 5 MHz, 10
MHz, 15 MHz, and 20 MHz
6x10M 1T1R
6x10M 1T2R
6x10M 2T2R
The following table lists the number of cells, bandwidth, and antenna configurations supported
by a single LBBP in LTE TDD scenarios.
BTS3900C (Ver.C)
Hardware Description 3 BTS3900C Modules
Issue 03 (2013-05-27) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
63
