– Version: V1R002C06-Later
d. Configure the working mode of a LAN port.
In the navigation tree, choose LANDevice > LAN Interface 1 > LAN
Interface > LAN Ethernet Configuration 1. Select LAN Ethernet
Configuration 1 and set LAN port two three-port enable to enable (indicating
that LAN 1 works in the Layer 3 mode).
NOTE
l If LAN port two three-port enable is disable, the LAN port works in the Layer 2
mode.
l If LAN port two three-port enable is enable, the LAN port works in the Layer 3
mode.
LAN port two three-port enable is defaulted to disable.
By default, the system has one LAN Ethernet Configuration 1 node. To add nodes,
select LAN Interface, right-click, and choose Add from the shortcut menu.
e. Configure parameters of a WAN port.
EchoLife HG8010/HG8110/HG8240/HG8245/HG8247/
HG8447 GPON Terminal
Service Manual 3 Configuration
Issue 02 (2011-12-08) Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
59
