3.1 Logging in to the ePico WebUI
This describes how to log in to the WebUI. For details about how to log in to the AP Manager,
see the AP Manager Operator Guide.
Prerequisite
l The ePico is powered on.
l The version of the web browser on the PC meets the requirement.
the Internet Explorer (IE) must be version 6.0 or later versions; When logging in to the
WebUI through the Internet Explorer 8.0, certain manual configuration is needed, Choose
Tools > Compatibility View Settings, In the Compatibility View Settings dialog box,
Choose Display all websites in Compatibility View, Click Close.
l The web browser does not use a proxy server.
To check whether the web browser uses a proxy server, perform the following steps where
IE 6.0 is taken as an example:
1. Open the IE. Choose Tools > Internet Options. The Internet Options dialog box
is displayed.
2. In the Internet Options dialog box, click the Connections tab. Then, click LAN
Settings.
3. In the Proxy server area, ensure that the check box Use a proxy server for your
LAN is not selected. Then, click OK.
Procedure
Step 1 Allocate an IP address for the computer. The IP address must be on the same network segment
as the IP address of the ePico.
NOTE
The default IP address of the ePico is 172.16.1.1, and the subnet mask is 255.255.255.0. To modify the
default IP address, do as follows:
1. Type http://172.16.1.1 in the address box of the web browser. Then, press Enter. The login dialog box
of the WebUI is displayed.
2. Click configuration.
3. Click TARGET IP in the left pane.
4. Click Mod.
5. Under Input Parameter Values, type the new IP address and the subnet mask. Then, click Done.
6. A message is displayed indicating that the change is successful. Exit the WebUI, and then log in to the
WebUI again by using the new IP address.
Step 2 Type the IP address of the ePico in the address box of the web browser. Then, press Enter. The
login dialog box of the WebUI is displayed, as shown in Figure 3-1.
3 ePico3801 Initial Configuration
ePico3801
User Guide
3-2 Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
Issue 01 (2009–09–23)
