3.6.6 Cabinet Base
Sliding bases are
congured for 1200 mm deep cabinets. The sliding feature is not
congured for 1100 mm deep cabinets.
A cabinet base has the following features:
● Cabinets are raised for 250 mm high and secured to bases, which are
anchored to the steel
oor using self-drilling tapping screws.
● To increase maintenance space, the cabinet needs to be slid. Sliding bases are
congured for 1200 mm deep cabinets. The 1200 mm deep cabinet sliding
base can be used to slide the cabinet frontward and backward for 200 mm.
● To prevent cabinets from sliding during the transportation of the pre-fab.
module if sliding bases are
congured, transport fasteners are installed at the
front and rear of the sliding bases. After the pre-fab. module is installed and
secured, the transport fasteners need to be removed.
● Cabinet bases can be used for cabinets that are 1100 mm and 1200 mm deep.
The bases can be 1100 mm or 1200 mm deep.
Figure 3-12 Cabinet sliding base
(1) Fixed leg
(2) Sliding platform (3) Transport fastener
3.7 External Ports of the Pre-fab. Module
End connectors are used at the ports designed for routing power cables, optical
bers, and network cables on the pre-fab. module exterior. All ports provide good
water tightness and thermal insulation performance, meeting equipment
compartment weather-tight requirements. Pipe feature an
anti-backow design,
adapting to dierent conguration demands. Fire extinguishing devices on the
pre-fab. module exterior meet sealing conditions.
Figure 3-13 External ports
FusionDC1000A Prefabricated All-in-One Data
Center
Product Description (IT Scenario) 3 Structural system
Issue 01 (2021-04-20) Copyright © Huawei Technologies Co., Ltd. 23
