FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
2 Typical Application Scenarios and Configurations
Issue 01 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
9
Item
Specifications
switch (optional)
Figure 2-4 Converged Cabinet+network cabinet
Table 2-4 Typical configuration 4
Item
Specifications
Cabinet dimensions (W x D x H)
600 mm x 1100 mm x 2000 mm
NOTE
Network cabinet dimensions (W x D x H):
600 mm x 1100 mm x 2000 mm or 800 mm x
1100 mm x 2000 mm
Power backup time
15–240 minutes
Power distribution
UPS2000-G, PDU5000, PDU2000, and
battery pack (optional)/external battery
(optional)
Monitoring
ECC800e, T/H sensor (Converged Cabinet),
T/H sensor (network cabinet, optional),
camera (optional), VCN500 (optional), door
status sensor (Converged Cabinet), door
