FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
2 Typical Application Scenarios and Configurations
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
status sensor (network cabinet, optional),
smoke detector, water sensor, pad
(optional), WiFi converter (optional),
infrared remote control module (optional),
GSM modem (optional), NetEco (optional),
independent deployment AI/DI unit
(optional), and LAN switch (optional)
Three-Cabinet Solution
Figure 2-5 Network cabinet+Converged Cabinet+battery cabinet
Table 2-5 Typical configuration 5
Cabinet dimensions (W x D x H)
600 mm x 1100 mm x 2000 mm
NOTE
Network cabinet dimensions (W x D x H):
600 mm x 1100 mm x 2000 mm or 800 mm x
1100 mm x 2000 mm
