Huawei FusionModule500 Manual

FusionModule500 Smart Mini Data Center
Product Description (ECC800e)
2 Typical Application Scenarios and Configurations
Issue 01 (2017-04-20)
Huawei Proprietary and Confidential
Copyright © Huawei Technologies Co., Ltd.
15
Item
Specifications
(optional), NetEco (optional), independent
deployment AI/DI unit (optional), and LAN
switch (optional)
Figure 2-9 Converged Cabinet+network cabinet
Table 2-9 Typical configuration 3
Item
Specifications
Cabinet dimensions (W x D x H)
600 mm x 1100 mm x 2000 mm
NOTE
Network cabinet dimensions (W x D x H):
600 mm x 1100 mm x 2000 mm or 800 mm x
1100 mm x 2000 mm
Power backup time
15–240 minutes
Power distribution
UPS2000-G, PDU5000, PDU2000, battery
pack (optional)/external battery (optional),
and transformer
Monitoring
ECC800e, T/H sensor (Converged Cabinet),
T/H sensor (network cabinet, optional),
