Item
Specifications
camera (optional), VCN500 (optional), door
status sensor (Converged Cabinet), door
status sensor (network cabinet, optional),
smoke detector, water sensor, pad
(optional), WiFi converter (optional),
infrared remote control module (optional),
GSM modem (optional), NetEco (optional),
independent deployment AI/DI unit
(optional), and LAN switch (optional)
Three-Cabinet Solution
Figure 2-10 Network cabinet+Converged Cabinet+battery cabinet
Table 2-10 Typical configuration 4
Item
Specifications
Cabinet dimensions (W x D x H)
600 mm x 1100 mm x 2000 mm
NOTE
Network cabinet dimensions (W x D x H):
600 mm x 1100 mm x 2000 mm or 800 mm x
1100 mm x 2000 mm
